Video/Audio Input

IP Video Input

Up to 64 IP Cameras (Max.64 wired cameras)
Up to 16 MP resolution

Device Compatible

All Reolink Cameras (except for 4G Cameras)

Audio Input

1 audio in channel, RCA; Via cameras with mic

Incoming Bandwidth

768Mbps

Outgoing Bandwidth

768 Mbps

Video/Audio Output

Video Output

2 HDMI

Display Resolution

HDMI: 3840x2160, 2560x1440, 1920x1080, 1280x1024, 1280x720, 1024x768

Audio Output

1 audio out channel, RCA

Decoding

Video Compression

Intelligent H.265+, H.265, H.264

Live View / Playback Resolution

7680X2160, 4608X1728; 4512X2512, 4096X3072, 3840X2160, 2560X2560, 2560X1920, 2560X1440, 2048X1536, 2304X1296, 1080P, 720P

Capability

64x896x512 @20fps
8x4MP @20fps
6x5MP @20fps
4x8mp @20fps
2x12MP @20fps
2x16MP @20fps

Synchronous Playback

Up to 4-channel playback (up to 8MP) or 1-channel playback (above 8MP)

Storage

SATA

4 SATA interface

Record Channels

64 channels

External HDD slot

N/A

Capacity

Up to 80TB (up to 20TB capacity for each HDD)

File Encryption

Yes

microSD Card Slot

N/A

External Interface

USB Interface

2 x UBS 2.0 + 1 x USB 3.0

Network Interface

8 x RJ-45, 10/100/1000 Mbps self-adaptive (for Switches)
1 x RJ-45, 10/100/1000 Mbps self-adaptive (for LAN/WAN)

Alarm In/Out

In: 8 channels; Out: 4 channels

PoE

Max. Power Per Port

N/A

Supported Standard

N/A

Network

Network Protocols

HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP

Browsers Supported

Edge, Firefox, Chrome, Safari

OS Supported

PC: Windows, Mac OS; Smart phone: iOS, Android

User Access

20 Users (1 admin account & 19 user accounts); supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams)

Other Features

AI Video Search

Yes

Heat Map

Yes

People Counting & Zone Crowd Monitoring

Yes (Camera Support Required)

Perimeter Protection

Yes (Camera Support Required)

Smart Event Detection

Forgotten Object (Camera Support Required)
Object Removal (Camera Support Required)

General

Power Supply

100-240 VAC, 50/60Hz, 1.5A

Power Consumption

<10W (without HDD & PoE)

Working Environment

Temperature: -10°C ~ + 45°C (14°F ~ 113°F);
Humidity: 10% ~ 90%

Dimensions

440*314.3*44mm

Weight

2.88kg(without HDD)
