Video & Audio

Image Sensor

1/2.49" CMOS sensor

Resolution

3840 x 2160 (8 Megapixels) @25fps

Lens

f=2.8mm/F2.0

Video Compression

H.265(more than 5MP)other H.264

Zoom

N/A

Field of View

Horizontal: 105° Vertical: 56° Diagonal: 125°

Infrared Night Vision

Up tp 30 meters(100ft); LED: 2pcs/2W/850nm (Auto-switching with IR-cut filter)

Color Night Vision

With spotlights: 2pcs/3w/3000K (Adjustable)

Frame Rate

Main stream: 2fps - 25fps (default: 25fps) Sub stream: 4fps - 15fps (default: 10fps)

Code Rate

Main stream: 1024Kbps - 8192Kbps (default: 6144Kbps) Sub stream: 64Kbps - 512Kbps (default: 256Kbps)

Audio

Two-way audio

Power Requirements

PoE

IEEE 802.3af, 48V, active

DC Power

DC 12.0V?1A, <12W

Interface

Power Port

DC power port

Ethernet Port

One 10M/100Mbps; RJ45

SD Card Slot

Supports Max. 256GB microSD card

Reset Button

YES

Audio In/Out

Built-in microphone and speaker

Software

Browsers Supported

Edge, Chrome, Firefox, Safari

OS Supported

PC: Windows, Mac OS; Smartphone: iOS, Android

Protocols & Standards

HTTPS, SSL, TCP/IP, UDP,HTTP,IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P

User Access

Max. 20 users (1 admin & 19 user); Max. 12 simultaneous streams (2 main & 10 sub streams)

Other Features

Smart Alarm

Motion detection; person detection; vehicle detection; animal detection

Recording Modes

Motion-triggered recording (default); Scheduled recording, 24/7 recording

Time Lapse

YES

Smart Home Compatibility

Google Assistant

Working Environment

Operating Temperature

-10°C~+55°C (14°F~131°F)

Operating Humidity

10% ~ 90%

Weatherproof

IP67

Mechanical

Dimensions

Φ117x 86mm

Weight Battery Included

604g

Warranty

Limited Warranty

2-year limited warranty. For support, visit https://support.reolink.com/hc/en-us/.
